[Specifications ]
规格与参数
| VLV聚氯乙烯绝缘聚氯乙烯护套电力电缆 | |||||||
| 标称截面 Nominal Cross-Sectional Area mm² | 线芯结构 （根/直径） Construction Of Conductor NO.of Wires/dia. mm | 绝缘厚度 Insulation Thickness mm | 护套厚度 Sheath Thickness mm | 计算外径 Calculated Outer Diameter mm | 空气中敷设 时载流量 Current Rating in Air | 埋地敷设 时载流量 Current Rating in Ground | 成品 近似重量 Approx. Cable Weight kg / km |
| 3×4+1×2.5 | 1/2.25+1/1.78 | 1.0/0.8 | 1.8 | 14.93 | 22 | 28 | 189 |
| 3×6+1×4 | 1/2.76+1/2.25 | 1.0/1.0 | 1.8 | 16.38 | 28 | 36 | 250 |
| 3×10+1×6 | 7/1.35+1/2.76 | 1.0/1.0 | 1.8 | 19.02 | 40 | 48 | 343 |
| 3×16+1×10 | 7/1.70+7/1.35 | 1.0/1.0 | 1.8 | 21.7 | 53 | 61 | 454 |
| 3×25+1×16 | 7/2.14+7/1.70 | 1.2/1.0 | 1.8 | 25.48 | 71 | 82 | 641 |
| 3×35+1×16 | 7/2.52+7/ 1.70 | 1.2/1.0 | 1.8 | 25.84 | 89 | 101 | 692 |
| 3×50+1×25 | 19/1.86+7/2.14 | 1.4/1.0 | 1.9 | 29.45 | 111 | 124 | 957 |
| 3×70+1×35 | 19/2.12+7/2.52 | 1.4/1.0 | 2 | 32.87 | 136 | 148 | 1253 |
| 3×95+1×50 | 19/2.52+19/1.78 | 1.6/1.2 | 2.2 | 38.19 | 168 | 177 | 1677 |
| 3×120+1×70 | 37/2.06+19/2.14 | 1.6/1.2 | 2.3 | 41.65 | 195 | 204 | 1953 |
| 3×150+1×70 | 37/2.30+19/2.14 | 1.8/1.4 | 2.4 | 45.34 | 228 | 233 | 2378 |
| 3×185+1×95 | 37/2.56+19/2.52 | 2.0/1.4 | 2.6 | 50.66 | 263 | 263 | 2913 |
| 3×240+1×120 | 37/2.95+37/2.03 | 2.2/1.6 | 2.8 | 56.56 | 302 | 295 | 3884.27 |
| 3×300+1×150 | 37/3.28+37/2.25 | 2.4/1.8 | 3 | 64.35 | 351 | 331 | 4774 |
| 4×4 | 1/2.25 | 1 | 1.8 | 15.51 | 22 | 28 | 224 |
| 4×6 | 1/2.76 | 1 | 1.8 | 16.74 | 28 | 36 | 279 |
| 4×10 | 7/1.35 | 1 | 1.8 | 19.86 | 40 | 47 | 344 |
| 4×16 | 7/1.70 | 1 | 1.8 | 22.4 | 53 | 61 | 497 |
| 4×25 | 7/2.14 | 1.2 | 1.8 | 26.61 | 71 | 82 | 666 |
| 4×35 | 7/2.52 | 1.2 | 1.8 | 26.32 | 89 | 101 | 826 |
| 4×50 | 19/1.86 | 1.4 | 1.9 | 30.45 | 111 | 124 | 1106 |
| 4×70 | 19/2.12 | 1.4 | 2 | 34.05 | 136 | 148 | 1475 |
| 4×95 | 19/2.52 | 1.6 | 2.2 | 39.6 | 168 | 177 | 1914 |
